Sand making machine/impact crusher

The Current Position：Home>>Products>>Brief Introduction

Sand making machine

YuHui PCL vertical shaft impact crusher (namely, sand making machine) is the specialized machine with international advanced level. Technology and modern processing make it a leading role in this industry. It is widely used for artificial sand, in metal and non-metal ores, cement, refractory material, bauxite, silicon carbide, glass material, building material. The finished sand has even particle size, high compressive strength, and high-purity. The stones fall from the top of the machine, and then it is divided into two parts by material-dividing plate. One enters into high-speed rotating impellor through the center of material-dividing plate. The other falls down from outside of material-dividing plate. Under the action of the high speed centrifugal force, the stones crushed the others distributed around the impeller in the form of umbrella. After the stones impact each other, the addying motion is formed between the impeller and main case to bring about many times’ mutual impacting, rubbing, and crushing till the granularity required is achieved

Main Technical Parameter:

Model	Max Feeding Size (mm)	Rotating plate diameter (mm)	Rotating speed (r/min)	Power (kw)	Capacity (t/h)	Weight (t)
PCL550	40	550	2000-3000	37-55	25-55	3.85-4.6
PCL750	45	750	1500-2600	75-110	65-120	6.85-7.6
PCL860	50	860	1200-2000	110-150	110-180	10-11.6
PCL1050	60	1050	1000-1750	132-220	190-270	16-17
PCL1250	70	1250	950-1350	264-400	280-380	18-19

Note: The technical parameters above are just for your reference. If there is any change, all parameters and overall dimension are subject to operating instructions. Any questions please feel free to contact us.
